| Standards: | BS1363 | BS1363-1-Fig 2a 2b: | Apparatus For Mechanical Strength Test On Resilient Covers |
|---|---|---|---|
| BS1363-1-Fig 5: | Gauge For Plug Pins | BS1363-1-Fig 7: | Mounting Plate |
| BS1363-1-Fig 8: | Plug Pin Deflection Test Apparatus For Resilient Plugs | BS1363-1-Fig 9: | Apparatus For Abrasion Test On Insulating Sleeves If Plug Pins |
| BS1363-1-Fig 10: | Apparatus For Pressure Test At High Temperatures | BS1363-1-Fig 24: | Ball Pressure Test Device |
| High Light: | BS1363 Plug Socket Tester,SGS Plug Socket Tester,BS546 Plug And Socket Measuring Gauges |
||
BS1363 Plug Socket Tester BS546 Plug And Socket Measuring Gauges
Specification:
| Product Model | Standard | Product Name |
| BS1363-1 | ||
| SC-B3F1 | BS1363-1-Fig 1 | Test pin |
|
SC-B3F2a SC-B3F2b |
BS1363-1-Fig 2a 2b | Apparatus For Mechanical Strength Test On Resilient Covers |
| SC-B3F5 | BS1363-1-Fig 5 | Gauge for plug pins |
| SC-B3F7 | BS1363-1-Fig 7 | Mounting plate |
| SC-B3F8 | BS1363-1-Fig 8 | Plug pin deflection test apparatus for resilient plugs |
| SC-B3F9 | BS1363-1-Fig 9 | Apparatus for abrasion test on insulating sleeves if plug pins |
| SC-B3F10 | BS1363-1-Fig 10 | Apparatus for pressure test at high temperatures |
| SC-B3F11 | BS1363-1-Fig 11 | Go gauge for socket-outlet(2 units/set) |
|
SC-B3F17a SC-B3F17b |
BS1363-1-Fig 17a/b | Temperature rise test device and the simulation panel |
| SC-B3F19 | BS1363-1-Fig 19 | Stainless steel solid fuse |
| SC-B3F23 | BS1363-1-Fig 23 | Press test device (include all parts) |
| SC-B3F24 | BS1363-1-Fig 24 | Ball Pressure Test Device |
| SC-B3F29 | BS1363-1-Fig29 | Correction clamp |
| SC-B3F32 | BS1363-1-Fig 32 | Apparatus for tests on plug pins (exclude the 1100N weight) |
| SC-B3F33 | BS1363-1-Fig 33 | Apparatus for torsion test on pins |
| BS1363-2 | ||
| SC-B32F1 | BS1363-2-Fig 1 | Test pin |
|
SC-B32F2a SC-B32F2b |
BS1363-2-Fig 2a 2b | Apparatus For Mechanical Strength Test On Resilient Covers |
| SC-B32F11 | BS1363-2-Fig 11 | Go gauge for socket-outlet(2 units/set) |
| SC-B32F12 | BS1363-2-Fig 12 |
Contact test gauge |
| SC-B32F14 | BS1363-2-Fig 14 | Non-contact test gauge |
| SC-B32F15 | BS1363-2-Fig 15 | Turning moment gauge |
| SC-B32F16 | BS1363-2-Fig 16 | Withdrawal pull gauge(2 units/set) |
|
SC-B32F17a SC-B32F17b |
BS1363-1-Fig 17a/b | Temperature rise test device and the simulation panel |
| SC-B32F19 | BS1363-2-Fig 19 | Stainless steel solid fuse |
| SC-B32F20 | BS1363-2-Fig 20 | Tumbling Barrel Tester |
| SC-B32F21 | BS1363-2-Fig 21 | Pendulum impact Tester |
| SC-B32F23 | BS1363-2-Fig 23 | Press test device |
| SC-B32F24 | BS1363-2-Fig 24 | Ball Pressure Test Device |
| SC-B32F29 | BS1363-2-Fig29 | Correction clamp |
| SC-B32F30 | BS1363-2-Fig 30 | Test plug for temperature rise |
| BS546 | ||
| SC-B5F2 | B.S546:1950 Fig 2 | Withdrawal-pull gauge for effectiveness of contact Gauge 2A,5A,15A,30A (8 units/set) |
| SC-B5F3 | B.S546:1950 Fig 3 | Go gauge for plug 2A,5A,15A,30A (4 units/set) |
| SC-B5F4 | B.S546:1950 Fig 4 | Max. “Go” gauge for socket-outlet 2A,5A,15A,30A (4 units/set) |
| SC-B5F5 | B.S546:1950 Fig 5 | Min. “Go” gauge for socket-outlet 2A,5A,15A,30A 2A,5A,15A,30A (4 units/set) |
Conforms To:
BS1363-1, BS1363-2
Application:
Shice equipment offers a wide range of gauge to meet the most common standards including those from IEC, EN, UL, DIN, VDE and others. Such standards require the checking of size & definition etc. these gauges are constructed from senior stainless steel and appropriate steel with a hardness of at least 52-58 HRC and a roughness according to standard require. Each gauge is supplied with a certificate of calibration.
